Upload your file/folder with ethfs-cli

PreviousTutorialsNextUse ethstorage-sdk to upload and download files

Last updated 2 months ago

Introduction

In this tutorial, we will demonstrate how to use the tool to upload files or folders to EVM-compatible chains such as beta testnet or Sepolia.

You can find the full list of currently supported chains .

For the content to be uploaded, let's assume that

  • there is a folder to be uploaded; (e.g., dist)

  • there are two files in the folder. (e.g., hello.txt and img/1.jpeg)

Step 1: Install ethfs-cli

If you have not already done so, you can install ethfs-cli using the following command:

npm i -g ethfs-cli

If you installed it a long time ago, please run the same command to update to the latest version.

Step 2: Create a FlatDirectory Contract

A contract serves as a container that needs to be created before uploading files.

Command Syntax

ethfs-cli create -p <private-key> -c <chain-id>

This command creates a FlatDirectory on a specified blockchain. You need to provide a private key and the chain ID.

If the part -c <chain-id> is omitted, Ethereum Mainnet will be specified by default.

Example: SWC Beta

ethfs-cli create -p 0x112233... -c 3335

You will get a FlatDirectory address after the transaction is confirmed on SWC beta testnet:

FlatDirectory: Address is 0xab351F35B82B20C1a253ae16523c5E2D60B56D6E

Example: Sepolia

ethfs-cli create -p 0x112233... -c 11155111

You will get a FlatDirectory address after the transaction is confirmed on Sepolia:

FlatDirectory: Address is 0x2f7696D4284358A2E8fDb4DF772dAd60c2c8fbAd

Step 3: Upload Files

In this section, you will upload the files/folder into the FlatDirectory that you just created.

Command Syntax

ethfs-cli upload \
    -f <directory|file> \
    -a <address> \
    -c <chain-id> \
    -p <private-key> \
    -t <upload-type>

You need to provide the contract address (-a <address>), chain ID (-c <chain-id>), private key (-p <private-key>), and the type of upload (-t <upload-type>).

Notice that you have 2 options to specify the file upload type: calldata, blob. The default type is blob which requires network support for EIP-4844.

If the part -c <chain-id> is omitted, Ethereum Mainnet will be specified by default.

Example: SWC Beta

ethfs-cli upload -f dist -a 0xab351F35B82B20C1a253ae16523c5E2D60B56D6E -c 3335 -p 0x112233...

Example log:

providerUrl = https://rpc.beta.testnet.l2.quarkchain.io:8545
chainId = 3335
address = 0xab351F35B82B20C1a253ae16523c5E2D60B56D6E
threadPoolSize = 15

FlatDirectory: The transaction hash for chunk 0 is 0x2526108470cb100837ac1a724df91c9ba3d1422fb2e45fec458cc3f566d5f210  hello.txt
FlatDirectory: Chunks 0 have been uploaded  hello.txt
FlatDirectory: The transaction hash for chunks 0,1,2 is 0xfec795480524f81964e62251e8ac7d0f0dc9ed8422bc96a300254377043d3721  img/1.jpeg
FlatDirectory: Chunks 0,1,2 have been uploaded  img/1.jpeg

Total File Count: 2
Total Upload Chunk Count: 4
Total Upload Data Size: 324.1015625 KB
Total Storage Cost: 2.259012840557991428 ETH

Example: Sepolia

ethfs-cli upload -f dist -a 0x2f7696D4284358A2E8fDb4DF772dAd60c2c8fbAd -c 11155111 -p 0x112233... -t blob

Example log:

providerUrl = https://rpc.sepolia.org
chainId = 11155111
address: 0x2f7696D4284358A2E8fDb4DF772dAd60c2c8fbAd


FlatDirectory: The transaction hash for chunk 0 is 0x809411aeb708023a33dadf17791d994dc3b4b2db1a6bbd36792bbedb68646978 img/1.jpeg
FlatDirectory: Chunks 0 have been uploaded hello.txt
FlatDirectory: The transaction hash for chunk 0 is 0x7cea7ea7e4898e03bee4fbc031799689dbe215bd6dd36733721150a099680be7 hello.txt
FlatDirectory: Chunks 0 have been uploaded img/1.jpeg

Total File Count: 2
Total Upload Chunk Count: 2
Total Upload Data size: 52.6513671875 KB
Total Storage Cost: 0.001492087764775451 ETH

Step 4: Download Your File!

Now you should be able to download the file you just uploaded.

Command Syntax

ethfs-cli download -a <address> -c <chain-id> -f <file>

Example: SWC Beta

ethfs-cli download -a 0xab351F35B82B20C1a253ae16523c5E2D60B56D6E -c 3335 -f img/1.jpeg

Example: Sepolia

ethfs-cli download -a 0x2f7696D4284358A2E8fDb4DF772dAd60c2c8fbAd -c 11155111 -f img/1.jpeg

Now, your file has been saved locally.

Step 5: Access Your File via web3://

Of course, you can also easily access the file you just uploaded using the web3:// protocol.

Example: SWC Beta

Example: Sepolia

Note: In the above URLs, you may need to specify a different chain ID than the one used in the ethfs-cli commands. This distinct chain ID is necessary for identifying the EthStorage network responsible for storing the files.

Optional: Using Your Own RPC Endpoint

You can also specify your own RPC for better performance by -r flag in the above steps.

For example when create FlatDirectory contract:

ethfs-cli create -p 0x112233... -c 11155111 -r http://...rpc.io

When uploading files:

ethfs-cli upload -f /Users/.../dist -a 0x2f7696D4284358A2E8fDb4DF772dAd60c2c8fbAd -c 11155111 -p 0x112233... -r https://...rpc.io

text:

image:

text:

image:

To gain further insights into web3:// protocol, you can visit .

ethfs-cli
Super World Computer
here
FlatDirectory
web3://0xab351F35B82B20C1a253ae16523c5E2D60B56D6E:3337/hello.txt
web3://0xab351F35B82B20C1a253ae16523c5E2D60B56D6E:3337/img/1.jpeg
web3://0x2f7696D4284358A2E8fDb4DF772dAd60c2c8fbAd:3333/hello.txt
web3://0x2f7696D4284358A2E8fDb4DF772dAd60c2c8fbAd:3333/img/1.jpeg
web3url.io
